PAGlink 94 (x4) w/ Dual Charger
PAGlink 94 (x4) w/ Dual Charger
DESCRIPTION
The PAGlink HC-PL94T Time Battery Gold Mount (14.8V, 94Wh) from PAG is a lithium-ion battery featuring a linking design that allows multiple units to be attached and used together. The capacities of all the units combine to provide a higher current draw and a longer run-time than if the individual units are used consecutively. A single unit supports a 10A draw while two units combine to provide a 12A draw.
Multiple units can be attached together when being used and when being charged. They're compatible with PAG and Gold mount (Anton Bauer) lithium-ion chargers. Up to eight can be linked per channel on select PAG chargers and up to four on Gold mount chargers (up to six with the right firmware). They stop charging once topped-off, so you can safely leave them on the charger rather than let them self-discharge on the shelf. Combined units form a network and communicate with one another to provide safe and efficient output. For example, when two units that have the highest states of charge in the group are linked one to the other, they are used as the ones to provide power to the camera, while the remaining units in the group wait in stand-by. Combined packs support hot swapping for continuous power supply. The HC-PL94T is also capable of sending capacity data to all supporting cameras.
The HC-PL94T features a numeric run-time and capacity display which maintains accuracy by tracking performance and adjusting calibration values to compensate for the aging of the cells. Run-time is expressed in hours and minutes and can be switched to a percentage figure. When linked for use, run-time is displayed for the entire pack. When being charged, each battery displays its individual status. The display characters can be changed at the press of a button for the character type more legible for you.
KEY FEATURES
High Current 14.8V, 94Wh, 6.4Ah Li-Ion
Linkable with Other Units for More Power
10A Draw; 12A When Two Units Combined
Numeric Run-Time and Capacity Display
